Center Seal Pouch Making Machine

1 Unit (MOQ)

Business Type Manufacturer, Exporter, Supplier
Driven Type Electric
Color Light White,Blue
Specialities Sturdy construction, Accurate alignment of parts, Superior strength, Consistent performance, Durable, Competitive prices
Click to view more

Preferred Buyer From

Location Anywhere in India

Product Details

410 V
3-5 kW

We are engaged in manufacturing high quality Center Seal Pouch Making Machine in customized as well as standard sizes. Having high strength and rugged construction, our Pouch Making Machinery is in huge in demand in the national market. Further, we provide our Center Seal Pouch Making Machine at the most reasonable price in the industry.

Type of Pouch Obtainable :

  • Bottom and Center Sealed Pouch - by folding process
  • 3-Side Sealed Pouch
  • From a single web Sheet
  • From Top-Bottom different web sheets
  • Registered Bottom Seal & Cutting by Electronic Photo- Sensor
  • Digital counter along with batch preset
  • Firm state AC control system
  • Alarm & totalizer
  • Shear cut by scissors action
  • Universal Rotatory Type anti-friction Gusseting system
  • Automatic pouch length adjustment with indicator
  • Automatic positional stop of machine
  • Firm state AC control system
  • Automatic dancing arm balancing
  • Superior Cool sealer for Compressed Sealing
  • Complete machine with Folding & Top-Bottom Unwinder, Tube Forming Section, Center Sealing and 3 Side
  • Sealing, Gusseting Bottom Sealing, Cutting and Collecting Table

Yes! I am interested

Technical Specifications

Max. Web Width 700mm
Max. Web Dia 500mm
Width of Pouch 50-350mm
Length of Pouch 50-400mm
Center Seal Width 4-100mm
Side Seal Width 5-20mm
Speed (approx) 80 pouch (min.)
Max. Connecting Load 6KW
Operational Load 3 KW
Size of Machine (LxWxH) 5700x1600x1800mm
Net Weight 2000kgs Approx.
